IEC 60529 Oscillating Tube Tester of Water Test Kits

Product Categories

SHENZHEN JULIXING INSTRUMENTS CO., LTD.

Contact Now

Place of Origin : Shenzhen China

Brand Name : Julixing

Certification : CNAS Test Report

Model Number : LX-X3/4

Types of companies : China Wholesale

Incoterms : CFR

Transportation : DHL Express

Product Type : Testing Equipment

MOQ : 1 set

Price : Contacts us

Packaging Details : Standard packing

Delivery Time : 15-20 Days

Payment Terms : T/T,Western Union

Supply Ability : 500 Set per month

Contact Now

IEC60529 IEC60335 IPX3 IPX4 Water Spray Test chamber

Application

The rain test system is strictly designed according to IEC60529. It’s applied to the Electrical equipment of the waterproof test of IPX3 and IPX4.

Technology Parameter

Power Supply	Single phase: AC220V, 50Hz
Swing Pipe diameter	19mm, thickness 2mm (304 stainless steel)
Swing Pipe radius	R200mm, R400mm, R600mm, R800MM, R1000mm, R1200mm, R1400mm, R1600mm;
Orifice diameter	0.4mm
Orifice angle	IPX3: 120°; IP4X: 180°
Pendulum Angle	IPX3: 120°(±60°); IPX4: 360°(±180°)
Swing Pipe Speed	EPX3: 4s/time (2x120°) IP4X: 12s/time (2x180°)
Water discharge	1-10L/min, adjustable
Test time	0-999mins, can preset
Adjustable telescopic pipe height	800-1700mm

IEC 60529 Oscillating Tube Tester of Water Test Kits Images
